Software systems developed for in-vehicle simulation tests such as autonomous driving, ADAS, intelligent cockpit, and hardware-in-the-loop simulation (HIL). It is mainly used for algorithm verification and optimization, data recharge, simulation injection, data acquisition and storage, video data analysis, sensor configuration management such as cameras and radars, CAN and vehicle network equipment configuration management, etc.
Used to configure the VSA100 to capture ECU configuration information for the camera, as well as other GMSL data, or to configure it for other functions; Parse IIC data, commonly used register configurations, display video, IIC, and timing of trigger signals; One-click generation of AUMO S1, S2 and other injection device configurations, VSA100 transparent transmission configuration.
1. Configure VSA100 to capture GMSL data, including IIC data, image parameters, and GPIOs
2. Configure VSA100 to capture the original image of the input video stream
3. Configure the timing of VSA100 to capture video, IIC, and trigger signals
4. Configure the DP and UVC interfaces of the VSA100 to output video
5. Configure VSA100 to transparently transmit GMSL data
6. The VSA100 is configured to inject a single channel with HDMI as the input source, and can quickly realize simulation injection by transparently transmitting the IIC data of the external camera and the embedded line data.
1. Parse IIC data to interpret commonly used register configurations
2. One-click generation of configurations available for injection devices such as AUMO S1 and S2
3. One-click generation of transparent transmission configuration for VSA100
4. Displays the timing of the video, IIC, and trigger signals
The configuration software for ADAS data reinjection and simulation injection application development can configure related sensors, decode and transcode video files, and support SDK secondary development.
1. Hardware management and maintenance
2. Configure camera information parameters
3. Test case configuration
4. Test case run management
5. Monitor test status
6. Support video file decoding and transcoding injection
7. Support the secondary development of SDK
The configuration management software for data acquisition is mainly used for camera configuration management, trigger synchronization management, time synchronization management, bypass mode configuration, CAN and vehicle network equipment configuration management, and data acquisition and storage management.
